LDAP Identity source and vCenter

Whenever we installed a new vCenter the activity always included integration with Active Directory and normally IWA (Integrated Windows Authentication) was used.
Since vSphere 7.0 version this possibility has been deprecated
so it is good to start with the integration of the vCenter with Active Directory via LDAP.
In our case, we will use LDAPS which uses a certificate

For first the step we need to create the certificate:

  • Use SSH to vCenter connection

On shell use this command

openssl s_client -connect <DC FQDN>:636 -showcerts

Copy the certificate output with  —–BEGIN CERTIFICATE—– and —–END CERTIFICATE—–

Past on Notepad and save with .crt extension

Now we will go to configure the Identity Sources on vCenter:

  • Login as Single Sign-On Administrator to vCenter
  • Navigate to Menu > Administration > Single Sign-On Configuration
  • In the Identity Provider tab, open Identity Sources
  • Click ADD
  • Select Active Directory over LDAP or OpenLDAP, depending on your directory type.

Fill out the remaining fields as follows:
Identity Source Name: Label
Base DN for users: The Distinguished Name (DN) of the starting point for directory server searches. Example: “DC=pollaio,DC=lan”.
Base DN for groups: The Distinguished Name (DN) of the starting point for directory server searches.
Domain name: Your domain name. Example: “pollaio.lan”
Domain alias: Your NetBIOS name. Example: “pollaio.lan”
Username: Domain user with at least browse privileges. Example: “pollaio\administrator”.
Connect to:  “ldaps://<DC FQDN>”.

  • Click Browse next to SSL Certificate
  • Select the .cer file created in before step
Now we are ready to login to the vCenter with domain user (remember to assign the correct permission to domain group or user group)

If you want check the correct use of SSL certificate on the authentication to Active Directory with LDAP connection check the websso.log:

LDAP Identity source and vCenter

VMware Skyline Advisor



VMware has had a product for a while now called VMware Skyline that provides proactive monitoring, analysis, and support for your VMware environment. It monitors your VMware installation and will notify you when issues arise.

Skyline Advisor will be available to customers and partners with active Production and Premier Support, VMware Success 360 and vRealize Cloud Universal subscriptions at no additional cost.

Create a Cloud Services Organization

Login with My VMware account associate to Production and Premier Support on the site:

https://console.cloud.vmware.com/
  •  After clicking Get Started, a new web browser page, or tab, will open. You will be asked to sign-in

with your VMware account. If you have an existing My VMware account, you can use those same

account details (email address/password) to sign in to Cloud Services.

  •  If you are existing VMware Cloud Services customer, you can choose an existing Cloud Services

Organization for Skyline. If you have never used VMware Cloud Services, click Create New

Organization.

  •  Enter a Organization Name.

Name your Organization something meaningful, that can be easily

referenced by both you, and VMware. For example, name your Organization after you Company, or

Business name. You can also append a line-of-business, division, or team, to the end of your

Company or Business name.

The following are example Organization Names:

The company, LOB, Company LOB, Company-vSphere, Company-Desktop

  • Enter an Address for your Organization.

Click Add Address. You can also choose an existing

address if one was found for your account. If you choose an existing address, skip to substep f.

During the creation of your Cloud Services Organization, your country currency, and Tax ID, may be

displayed. The displaying of this information is a construct of Cloud Services. Skyline is available at

no additional cost, and you will not be required to enter any payment details while adopting Skyline.

  • Select a Country from the drop-down menu.
  •  Enter your street address on Address Line 1, and Address Line 2 (optional).
  • Enter your City.
  • Enter your State/Province.
  • Enter your Zip/Postal Code.
  • Review the Cloud Services Terms of Service. Click the checkbox to agree to the Terms of Service.
  • Click Continue.

Now on service, we have Skyline Advisor, click on this service

Link the Entitlement

Now, after clicking on LINK, we have the correct status LINKED


Deploy Skyline Collector and configure the connection to Cloud Services

Now we download the Skyline collector
https://vmware.com/go/skyline-collector-download

Download VMware Skyline Collector
Select Version:
•roduct Downloads
Product
VMware Skyline is an innovative proactive support offering that brings high-performing technology and tools to the workbench to
radically transform customer support
Automatically and securely collect product usage data with VMware Skyline Collector. Environment-specific analytics based on
configuration, feature, and performance data are executed against this data. The resulting information may radically improve
Read More
Product Resources
View My Download History
Product Info
Documentation
Community
Drivers & Tools
Open Source
Custom ISOS
VMware Skyline Collector 28.0
OEM Addons
Release Date
2021-07-15
GO TO DOWNLOADS

To deploying the Skyline Collector Virtual appliance on our vSphere infrastructure we have need:

Resource Requirements
vCPU
RAM
Disk Space
87Ga (1.1 thin-
provisioned)

And these are the Network Requirements

External Network Requirements
Connection From
Skyline Collector
Skyline Collector
Connection To
vcsa_vmwarecom
vapp-updates_vmwarecom
Type
H TTPS
H TTPS
Protocol
T CP/1p
T CP/1p
Protocol
TCP/Ip
TCP/Ip
TCP/Ip
TCP/Ip
TCP/Ip
TCP/Ip
TCP/Ip
TCP/Ip
TCP/Ip
TCP/Ip
443
443
Internal Network Requirements
Connection From
Skyline Collector
Skyline Collector
Skyline Collector
Skyline Collector
Skyline Collector
Skyline Collector
Skyline Collector
Skyline Collector
Skyline Collector
Web Browser
Connection To
vCenter Server
ESXi Hypervisor Hosts
5.5 psc/sso Provider
6.0 and above psc/sso
Provider
NSX-V Manager
NSX-T Manager nodes cluster
virtual P address (VIP)
Horizon Connection Server
vRedlize Operations Manager
SDDC Manager
Skyline Collector
Type
443
443
443
443
443
443
443
443
443




Account permission for vCenter, we need to create a Domain Account to use to permit access to vCenter from skyline.

• vCenter Server Read-Only role
• GlobalDiagnostics
• Globalkealth
• GlobalLicenses
• GlobalSettings
• Host profile.View
Let’go we are starting with the OVF Deploy
Deploy OVF Template
1 Select an OVF template
2 Select a name and folder
3 Select a compute resource
4 Review details
5 Select storage
6 Ready to complete
Select an OVF template
Select an OVF template trom remote URL or local file system
Enter a URL to download and install the OVF package trom the Inn
location accessible trom your computer, such as a local hard drive.
CD/DVD drive.
O URL
@ Local file
Scegli i file




Deploy OVF Template
1 Select an OVF template
2 Select a name and folder
3 Select a compute resource
4 Review details
5 Select storage
6 Ready to complete
Select a compute resource
Select the destination compute resource for
v VDICEDB
v VDlRPLcluster
Phesx07.






Deploy OVF Template
1 Select an OVF template
2 Select a name and folder
3 Select a compute resource
4 Review details
5 License agreements
6 Select storage
7 Select networks
8 Customize template
9 Ready to complete
Template name
Download size
Size on disk
Folder
Resource
Storage mapping
All disks
Network mapping
Network I
IP allocation settings
IP protocol
IP allocation
Properties
557.6 MB
87.0 Ga
austerVSAN
Policy: Stretched Mirror - No space reservation No Local Protection; Datastore: vsanDatastore; Format: A
s defined in the VM storage policy
DPG-IT
1 pv4
Static - Manual
Default Gateway =
Domain Name = VISKYOI
Domain Search Path
Domain Name servers = 172 16
Network 1 P Address = 172 16 20.33
Network 1 Netmask = 255
CANCEL
BACK
FINISH




You must change your password on first login.
Old Password
New Password
Repeat New Password
CHANGE
@ Your password was changed successfully!
LOGIN AGAIN
Password Requirements
• Minimum length: 8 characters
• One uppercase letter.
• One special case letter
• One digit.
• One lowercase letter.

Skyline Collector
admin
For Active Directory login username format must be "user@domain"
LOG IN



After deployed the Connector virtual appliance we need to configure the Skyline Collector for communicating with Cloud Services


After you have finished Linking Entitlement Accounts to your Cloud Services Organization, click Skyline Collector Setup.
O COLLECTOR SETUP


Initial Configuration
1 Network Configuration
CELP Terms and Conditions
Collector Registration
Continue Configuration
Collector Name
6 Auto-upgrade
Configure vCenter Server
8 Configure NSX-V (optional)
Configure NSX-T (optional)
10 Configure Harizor View (op-.iona ,
Configure *'Realize Operations
Network Configuration
Hostname Verification
By enabling Hostname Verification you add an additional check
This will ensure the client is connecting to the appropriate server
"subjectAItName" fields against the host in the URL of the conne
NOTE: Enabling this option will likely break any traffic intercept
generating certificates correctly.
Hostname Verification
Proxying
Proxy
TEST & SAVE
C) Enabled
Disabled

Test the network configuration
@ Successfully set Network Configuration!

Initial Configuration
1 Network Configuration
2 CEIP Terms and Conditions
Collector Registration
Cortinue Configuration
Collector Name
6 Auto-upgrade
Configure vCenter Server
8 Configure NSX-V (optional)
Configure NSX-T (optional)
10 Configure Harizor View (optional
Customer Experience Improvement Program (CEIP)
As part of the Enhanced Customer Experience Improvement Program ("CEIP"), VMware Skyline collects
certain technical data and product logs about your organization's use of VMware products and services
on a regular basis. The data collected may include device identifiers and information that identifies your
users. This data is collected to enable VMware to diagnose and improve its products and services, fix
product issues, provide proactive technical support and to advise you on how best to deploy and use
our products
For additional information regarding the CEIP, please see the Trust & Assurance Center at
https://wwwvmware.com/solutions/trustvmware/ceip_
By configuring your VMware products to participate in the Skyline service, each product will be enabled
to send product usage data to the Skyline services as part of the Enhanced Customer Experience
Improvement Program. You may add, remove or modify your product configurations at any time. For
detailed instructions see our Skyline Collector User Guide
To disable participation in the Customer Experience Improvement Program, you must Deregister this
Skyline Collector. For instructions how to Deregister a Skyline Collector, see VMware Knowledge Base
Article 74677.

And now we have to insert the token create on Cloud Service

Initial Configuration
2
3
6
8
Network Configuration
CEP Terms and Conditions
Collector Registration
Continue Configuration
Collector Name
Auto-upgrade
Configure vCenter Server
Configure NSX-V (optional)
Configure NSX-T (optional)
Collector Registration
VMware Skyline is now part of VMware Cloud Services. VMware Cloud Services uses the concept of
"Organizations" to provide controlled access to one or more services.
You can create an "0rganization" on the VMware Cloud Services Platform by following the steps
described in the link below:
You can generate a token on VMware Cloud Services Platform and enter it below in order to associate
your Skyline Collector to the Organization.
Collector Registration Token
Paste Collector Registration Token Here

Get Token from Vmware Cloud Services Platform

VMware Cloud Services

I have already configured my organization

Copy and paste the token on Skyline Connect and register it.

Add source Data to Skyline Advisor

After complete the step 5 and 6 (I suggest to enable the auto-upgrade), we can access to skyline collector to configure the connection to vCenter (or multiple vCenter)

Go to https://<mySkylineCollectorFQDN/

Select Add a vCenter  Server

Use the Account AD to whom assign the correct permission on vCenter

We are able to see the vSphere infrastructures if we access on Skyline Advisor Service on Cloud Service Link

https://console.cloud.vmware.com/

Now we will be waiting….. for data populate (72 hours for Findings)

After 72 hours we are able to see all info   (wow I see six Critical alerts :-))

VMware Skyline Frequently Asked Questions (55928)

Skyline Collector User Accounts and Permissions (vmware.com)

VMware Skyline Advisor

VMware vSAN 7 Update 3 New Features

VMware vSAN 7 Update 3 New Features

With the release of VMware vSphere 7 Update 3, this also means there is a new version of vSAN as well. VMware vSAN has been trailblazing in the world of HCI for several years now and with over 30,000 customers and many releases behind it, the solution has certainly grown, matured, and become […]


VMware Social Media Advocacy

VMware vSAN 7 Update 3 New Features
